我国电能表检定系统校验技术达国际领先水平
来源:
|
作者:202302119160975
|
发布时间: 3472天前
|
1444 次浏览
|
分享到:
12月18日，“电能计量器具自动化检定系统检定装置校验技术研究”项目通过评审，该项目由国网天津电科院牵头开发，评审专家对该项目给予高度评价。
由JJG596、597和1085等国家技术规范的主要起草人及国内知名计量专家组成的专家组对“电能计量器具自动化检定系统检定装置校验技术研究”项目建设给予高度评价，认为达到国际领先水平。
评审专家组先后听取了项目工作情况汇报，详细审查了技术文件和相关资料，并现场核查项目系统的运行情况，经讨论认为项目相关资料齐全、完整、规范，符合评审要求，项目整体技术达到国际领先水平。
该项目于2015年4月正式启动，研制出适用于电能表自动化检定流水线在线实时监测的0.02级微型标准电能表。设备采用低功耗设计等先进技术，解决了标准表预热时间长的行业难题，并利用微型标准表和可编程故障表，提出一种新的电能表自动化检定系统量值溯源与质量保障方法，优化了交流电能表检定装置检定流程，实现了检定系统不停产检定及溯源。
项目投入运行后，电科院计量中心可根据需要随时检测自动化检定流水线的计量性能，在高效率的同时保证了自动线的持续的高计量性能，有效减少甚至杜绝电能表自动化检定系统的质量隐患，提高公司计量检定能力，完善管理制度，为智能电网建设提供有力支撑。
